| Standard Machine |
| Test Load |
10,25, 50, 100, 200, 300, 500, 1000kgf |
| Load Control |
Automatic (Loading, duration & unloading) |
| Load Duration |
5 to 90 seconds in 1-second increments |
| Accuracy |
± 1% |
| Resolution |
.01μm |
| Max. Specimen Height |
90mm |
| Max. Specimen Depth |
100mm |
| Power Supply |
240V 60Hz Single Phase |
| Weight |
~42kg |
| Further Information |
- Operator Activated start function from minor load position
- Constant Loading Speed
- Variable or automatic load duration function
- Hardness number offset function
- RS232/Digimatic Output enabling linkage with any Mitutoyo processor
- Special purpose safety light to protect indentor and monitor test piece
- Telescopic Leadscrew Cover
|
