MÁY ĐO ÁNH SÁNG KONICA T-10A
- Giá : Liên hệ
- MASP : T-10A
- Nhà sản xuất : KONIKA MINOLTA
- Dụng cụ chiếu sáng trong nhà, hoạt động nghiên cứu của các nhà máy sản xuất. Công xưởng, tất cả ngành công nghiệp, phòng bảo vệ của bệnh viện. Xây Dựng kiến trúc liên quan đến ánh sang. Nông nghiệp, lâm nghiệp về phương diện quản lí độ chiếu sáng.
Chi tiết Sản phẩm
T-10A and T-10MA Illuminance Meter
|
Model |
IlluminanceMeter T-10A (Standard receptor head) |
IlluminanceMeter T-10MA (Mini receptor head) |
IlluminanceMeter T-10WsA (Waterproof mini receptor head) |
IlluminanceMeter T-10WLA (Waterproof mini receptor head)
|
||
|---|---|---|---|---|---|---|
|
Type |
Multi-function digital illuminance meter with detachable receptor head (Multi-point measurements of 2 to 30 points is possible) |
|||||
|
Illuminance meter class |
Conforms to requirements for Class AA of JIS C 1609-1: 2006 “Illuminance meters Part 1: General measuring instruments” Conforms to DIN 5032 Part 7 Class B |
Conforms to requirements for specialIlluminance meters of JIS C 1609-1: 2006*1 |
||||
|
Receptor |
Silicon photocell |
|||||
|
Relative spectral response |
Within 6% (f1´) of the CIE spectral luminous efficiency V (ƛ) |
|||||
|
Cosine response (f2) |
Within 3% |
Within 10% |
||||
|
Measuring range |
Auto range (5 manual ranges at the time of analog output) |
|||||
|
Measuring function |
Illuminance (lx). Illuminance difference (lx). Illuminance ratio (%). Integratedilluminance (lx·h). integration time (h). average illuminance (lx). |
|||||
|
Measuring range |
Illuminance |
0.01 to 299,900 lx; 0.001 to 29,990 fcd |
1.00 to 299,900 lx; 0.1 to 29.990 fcd *2 |
|||
|
Integratedilluminance |
0.01 to 999,900 x 103 lx·h 0.001 to 99,990 x 10*3 fcd·h / 0.001 to 9999 h |
|||||
|
User calibration function |
CCF (Color Correction Factor) setting function: Measurement value x 0.500 to 2.000 |
|||||
|
Linearity |
±2% ±1 digit of displayed value |
|||||
|
Temperature/ humidity drift |
Within ±3% |
|||||
|
Digital output |
USB |
|||||
|
Analog output |
1 mV/digit, 3 V at maximum reading; Output impedance: 10 K Ω; 90% response time: 28 ms |
|||||
|
Display |
3 or 4 Significant-digit LCD with backlight illumination (Automatic illumination) |
|||||
|
Power source |
2 AA-size batteries / AC adapter AC-A308 (optional; for 1 to 10 receptors) or AC adapter AC-A311 (optional; for 1 to 30 receptors) |
|||||
|
Battery life |
72 hours or longer (when alkaline batteries are used) in continuous measurement |
|||||
|
Operating temperature/ humidity range |
-10 to 40°C, relative humidity 85% or less (at 35°C) with no condensation |
5 to 40°C, relative humidity of 85% or less (at 35°C) with no condensation |
||||
|
Storage temperature/ humidity range |
-20 to 55°C, relative humidity 85% or less (at 35°C) with no condensation |
0 to 55°C, relative humidity of 85% or less (at 35°C) with no condensation |
||||
|
Dimensions |
69 x 174 x 35 mm |
Main body : 69 x 161.5 x 30 mm Receptor: Ø16.5 x 13.8 mm |
||||
|
Cord length |
- |
1 m |
5 m |
10 m |
||
|
Weight (without battery) |
200 g (7.0 oz.) |
205 g |
260 g (Receptor head only: 120 g) |
340 g (Receptor head only 200 g) |
||
*1 Conforms to requirements for Class AA of JIS C 1609-1:2006 for all items except cosine response (f2).
*2 Although measurements below 1.00 lx are possible, they may not be stable due to the effects of electrical noise.
*Do not touch the cable during measurements. Doing so may result in unstable measurement values.
*Secure the cable during measurements. Failure to do so may result in unstable measurement values.
