TM
Analog Torque Meter
|
|
|
| |
|
|
| |
- Dial indicating with Memory Pointer
- Ideal for Testing Torque on Caps
- Models available in single SI scale or dual American/Metric scales
|
|
| |
|
|
| |
 |
| TM-S features red follower hands that remain at peak torque after testing. |
| |
|
|
| |
Select proper model according to unit of measure as following color code : |
|
| |
| S.I. = |
|
|
Metric = |
|
|
American = |
|
|
Accuracy ±2%
|
|
| |
| Model |
Torque Range |
Dimension |
Chuck |
Weight Approx. |
| Single Scale |
Dual Scale |
| S.I. |
Metric/American
|
Min.-Max. |
Graduation |
Overall length |
Overall Width |
Overall Height |
| S.I. |
METRIC |
AMERICAN |
S.I. |
METRIC |
AMERICAN |
| 4TM10MN-S |
4-TM100-A-S |
mN.m
1-10 |
gf.cm
10-100 |
in.lbs
0.01-0.86 |
mN.m
0.2 |
gf.cm
2 |
in.lbs
0.02 |
252 mm
9 29/32 in |
158 mm
6 7/32 in |
105 mm
4 1/8 in |
Ø14 ~ Ø110 mm
9/16 ~ 4 11/32 in |
3 kg
6 21/32 lbs. |
| 4TM15MN-S |
4-TM150-A-S |
1.5-15 |
15-150 |
0.02-0.13 |
0.5 |
5 |
0.05 |
| 4TM25MN-S |
4-TM250-A-S |
2.5-25 |
25-250 |
0.25-0.215 |
| 4TM50MN-S |
4-TM500-A-S |
5-50 |
50-500 |
0.05-0.43 |
1 |
10 |
0.1 |
| 4TM75MN-S |
4-TM750-A-S |
8-75 |
80-750 |
0.08-0.65 |
2 |
20 |
0.2 |
| 3TM10CN-S |
3-TM1-A-S |
cN.m
1-10 |
kgf.cm
0.1-1 |
0.1-0.86 |
cN.m
0.2 |
kgf.cm
0.02 |
0.02 |
| 3TM15CN-S |
3-TM1.5-A-S |
1.5-15 |
0.15-1.5 |
0.15-1.3 |
0.5 |
0.05 |
0.05 |
| 3TM25CN-S |
3-TM2.5-A-S |
2.5-25 |
0.25-2.5 |
0.25-2.15 |
| 3TM50CN-S |
3-TM5-A-S |
5-50 |
0.5-5 |
0.5-4.3 |
1 |
0.1 |
0.1 |
| 3TM75CN-S |
3-TM7.5-A-S |
8-75 |
0.8-7.5 |
0.8-6.5 |
2 |
0.2 |
0.2 |
| 2TM100CN-S |
2-TM10-A-S |
10-100 |
1-10 |
1-8.6 |
331 mm
13 1/32 in |
223 mm
8 25/32 in |
133 mm
5 1/4 in |
Ø18 ~ Ø190 mm
11/16 ~ 7 15/32 in |
10.5 kg
23 11/32 lbs. |
| 2TM150CN-S |
2-TM15-A-S |
20-150 |
2-15 |
2-13 |
| 2TM200CN-S |
2-TM20-A-S |
30-200 |
2-30 |
3-17 |
5 |
0.5 |
0.5 |
| 2TM300CN-S |
2-TM30-A-S |
30-300 |
3-30 |
3-26 |
| 2TM400CN-S |
2-TM40-A-S |
40-400 |
4-40 |
3.5-35 |
| 2TM500CN-S |
2-TM50-A-S |
50-500 |
5-50 |
4-43 |
10 |
1 |
1 |
| 2TM600CN-S |
2-TM60-A-S |
60-600 |
6-60 |
5-50 |
| 2TM750CN-S |
2-TM75-A-S |
80-750 |
8-75 |
7-65 |
|
|
| |
 |
|
| |
Metric/ American model has dual scale. SI Models have only one scale. |
